Description
Magnification: 9x
Lens diameter: 45 mm
Field of view: 117 m at 1000 m
Minimum focus: 7 m
Exit pupil: 5 mm
Prism arrangement: Roof
Twilight efficiency: 18.3
Measuring range: 13.5 – 2377 m
Measurement accuracy: +/- 1 m up to 1 km, +/- 2 m above 1 km
Power supply: CR2 3V (not included)
Water resistance: IPX7
Measurement speed: max. 0.25 s
Measurement angle: from – 70 deg. to 70 deg.
Laser beam length: 905 nm
Laser class: 1
Display brightness adjustment: 5 degrees
Measurement modes: 4
Scanning mode: yes, up to 20 s
Dimensions: 154 x 127 x 68 mm
Weight: 965 g
